Bianchi Arcadex GRX815 Di2 Bike


$3,19900 $7,00000

Color 2
Size
Bianchi  |  SKU: YRBX6UMDGX


Bianchi Arcadex GRX815 Di2 Bike Info

The Bianchi Arcadex is a carbon gravel bike that can do it all from racing to training or simply exploring nature. This fast and responsive machine is made for the modern gravel rider who wants the ability to perform on virtually any terrain without sacrificing speed or weight. It offers the speed and aesthetics that you prefer in a road bike along with the ability to fit 700c or 650b tires depending on what kind of riding you have planned. The Arcadex name is inspired by Arcadia which in Greek and Roman mythology was tied to visions of natural harmony. The Bianchi Arcadex will help you connect your love of cycling and your love of nature, providing a fast and fun ride on any terrain imaginable.

The frame of the Bianchi Arcadex is made with a lightweight carbon fiber material, making it almost as light and stiff as your road bike. It also has many aerodynamic features, refusing to sacrifice pure speed for its ability to venture off the road. The frame can accommodate mudguards, so you can keep your bike safe from the elements when you decide to take on some gnarly terrain. At the front, you will find an integrated cockpit, featuring an ACR headset and a streamlined connection between the frame and stem with a custom headtube and spacers. The Arcadex has all the top qualities of a road bike with added gravel capabilities.

Like all Bianchi bikes, the Arcadex includes a unique look and color scheme. You will notice signature Bianchi colors and a design unlike any other brand. This is the premier version of the Arcadex, equipped with a Shimano GRX815 Di2 groupset for gravel-specific 11-speed electronic shifting. Every component on the Arcadex is made specifically to conquer gravel rides with more confidence than ever. The Bianchi Arcadex is a high-level machine for taking on the toughest challenges.

Bianchi Arcadex GRX815 Di2 Bike Specifications

Frame Material:
Carbon, 12x142mm Thru-Axle
Fork:
Full Carbon, 12x100mm Thru-Axle
Headset:
FSA SMR HS
Seatpost:
Reparto Corse UD Carbon, 31.6mm
Front Derailleur:
None
Rear Derailleur:
Shimano GRX Di2 RX817
Crankset:
Shimano GRX RX810, 40t
Bottom Bracket:
Shimano BB72-41B
Brake Calipers:
Shimano GRX RX810
Rotors:
Shimano RT800, 160mm
Shifters / Levers:
Shimano GRX Di2 RX815
Cassette:
Shimano XT M8000, 11-42
Chain:
Shimano HG701
Wheel - Front:
Fulcrum Rapid Red 500 DB
Wheel - Rear:
Fulcrum Rapid Red 500 DB
Stem:
FSA OS-188
Handlebar:
Aluminum 6061 Aero
Saddle:
Fizik Argo Tempo R5
Tires:
WTB Riddler Race, 700x37c
Pedals:
Not Included

*Specifications are subject to change.

Bianchi Arcadex GRX815 Di2 Bike Geometry

Bianchi Arcadex GRX815 Di2 Bike Geometry
Size:
M
XL
XS
B. Seat Tube (c-t)
520
580
440
C. Top Tube Length
550
585
522
D. Head Tube Length
150
180
120
E. Chain Stay Length
425
425
425
G. Seat Tube Angle
73.5
73
74.5
H. Head Tube Angle
71
71
70.5
J. Wheel Size
700c
700c
700c
K. Stack
595
623
565
L. Reach
374
394
365
