5DEV RGXC Titanium Cranks

5DEV RGXC Titanium Cranks Info

5DEV RGXC Titanium Cranks represent the pinnacle of 5DEV’s road, gravel, and XC crank design—combining advanced manufacturing, modular fit options, and titanium durability into a single, highly adaptable platform. CNC-machined and laser welded using an in-house robotic welding system, these cranks are engineered for riders who demand precision, longevity, and flexibility across multiple disciplines.

Designed as a true multi-surface crankset, the RGXC Titanium Cranks are equally at home on road race bikes, gravel builds, and XC machines. The low-profile crank tip reduces rock strikes on technical terrain, while the refined geometry supports efficient power delivery and stable pedaling dynamics across long rides and high-intensity efforts.

Compatibility is at the core of the RGXC system. The cranks use a SRAM 8-bolt interface and work seamlessly with all Quarq 8-bolt power meter spiders. A modular spindle system allows riders to fine-tune fit and chainline for road, road-wide, or XC applications—and spindles can be swapped at no cost after purchase to ensure the correct setup.

5DEV RGXC Titanium Cranks Specs at a Glance

• Material: CNC-machined titanium, laser welded
• Crank Interface: SRAM 8-bolt
• Power Meter Compatibility: All Quarq 8-bolt spiders
• Available Lengths: 155 mm, 160 mm, 165 mm, 170 mm, 175 mm
• Weight: 446 g (170 mm with road spindle)
• Torque Specification: 50 Nm
• Warranty: Lifetime warranty
• Manufacturing: Made in San Diego, California, USA

Fit & Geometry

• Q-Factor: 152 mm (Road), 160 mm (Road Wide), 166 mm (XC with 55 mm chainline)
• I-Factor: 126 mm (Road), 134 mm (Road Wide), 140 mm (XC)
• Spindle Options: Compatible with all 5DEV spindle widths, optimized for 118 mm (Road), 122 mm (Road Wide), and 130 mm (XC)

Design Benefits

1. Advanced Titanium Construction: Robotic laser welding delivers consistent strength and precision.
2. Highly Modular: Interchangeable spindle system adapts to multiple bike platforms.
3. Low-Profile Tip: Reduces rock strikes on gravel and XC terrain.
4. Premium Hardware: Diamond-coated titanium hardware improves corrosion resistance and longevity.

Important Installation Notes

• Always use anti-seize or grease when installing pedals.
• Titanium pedal spindles are not recommended with titanium crank arms.

Final Take

The 5DEV RGXC Titanium Cranks are a no-compromise solution for riders who want one crankset capable of spanning road, gravel, and XC use. With cutting-edge manufacturing, modular fit options, and a lifetime warranty, they’re built to anchor a premium drivetrain for years of hard riding.
