Van Rysel RCR-F Pro - Born for the Breakaway

Service Blog Login

Pivot Firebird Pro XT/XTR FOX Float X2 Bike


$5,99900 $7,99900

Color
Size
Pivot  |  SKU: V329AXTAORGSMDRPFN | Option: Orange, S

Questions about this product?

What size do I need?

Get a digital fit assessment

Schedule a Bike Fit in Walnut Creek, CA.

Schedule a Bike Fit in Brooklyn, NY. Please call 718-636-5242


* Product image may vary. Refer to the description for accurate details.

Pivot Firebird Pro XT/XTR FOX Float X2 Bike Info

The Pivot Firebird Pro XT/XTR is a high-level endurance trail bike that is fast, fun, and stable in any situation. Pivot says that the Firebird “rewrites the 29er playbook” with its ability to fly up climbs and just as easily bounce down a technical descent. While there are plenty of 29-inch endurance bikes that can take on technical terrain and bomb downhills, there are few as lightweight and capable of climbing or sprinting like the Firebird. This version is equipped with a combination of Shimano XT and XTR components for high-level 12-speed trail shifting at a lower price. Used by a ton of Pivot’s professional racers, the Firebird is worthy of world-class riding.

The frame of the Pivot Firebird is made with a lightweight carbon fiber, making it lighter than the majority of bikes in its class. Pivot’s engineering process utilizes hollow-core carbon and a high compression molding process. This leads to an incredibly light frame that compensates for the extra grams caused by 29-inch wheels. This version features alloy DT Swiss XM1700 wheels for a lower price and prime durability. The engineering process also leads to a frame that is strong enough to withstand the most aggressive World Cup downhill punishment. With its carbon build and capable suspension, the Firebird strikes a seemingly impossible combination of low weight and durability.

When it comes to stability at high speeds, the Pivot Firebird is hard to compete with. It features the longest reach in its class along with incredibly short chainstays. This allows for a much lower center of gravity and low riding position. A 65-degree slack angle also helps the rider stay low and in position for unmatched stability. With 165mm of travel at the rear and 170mm at the front with an offset suspension fork, the Pivot Firebird can take on any challenge while leaving the rider feeling completely in control. This version utilizes a Fox Factory Float X2 suspension and Factory 38 fork for professional level compliance. The Pivot Firebird is ready to dominate any obstacles the trail throws its way.

Pivot Firebird Pro XT/XTR FOX Float X2 Bike - Specifications

Frame Material:
Carbon
Fork:
Fox Factory 38 29", 44mm offset, GRIP2 - 170mm
Rear Suspension:
Fox Factory Float X2
Headset:
Pivot Precision Sealed Cartridge
Seatpost:
Fox Transfer Factory Series 150mm (SM), 175mm (MD-LG), 200mm (XL)
Front Derailleur:
None
Rear Derailleur:
Shimano XTR M9100 SGS 12-Speed
Crankset:
Race Face Æffect R 32t
Bottom Bracket:
Race Face
Brake Calipers:
Shimano XT M8120 4-piston
Brake Levers:
Shimano XT M8120 4-piston
Rotors:
Shimano XT CenterLock - 203mm
Shifters:
Shimano XT M8100 ISPEC EV 12-Speed
Cassette:
Shimano XT M8100 10-51t
Chain:
Shimano CN-M8100 12-Speed
Wheel - Front:
DT Swiss XM1700 w/ DT Swiss 350 hub & 36t Star Ratchet 30mm - 29" 15x110
Wheel - Rear:
DT Swiss XM1700 w/ DT Swiss 350 hub & 36t Star Ratchet 30mm - 29" 12x157
Stem:
Phoenix Team Enduro/Trail
Handlebar:
Phoenix Team Low Rise Carbon - 800mm
Saddle:
Phoenix WTB Volt Pro (Medium Width)
Tires:
Maxxis Minion DHF 29" x 2.5" WT, TR, 3C, EXO+, MAXXTERRA / Maxxis Minion DHRII 29" x 2.4" WT, TR, 3C, EXO+, MAXXTERRA
Grips:
Phoenix Factory Lock-On
Pedals:
Not Included

*Specifications are subject to change.

Pivot Firebird Pro XT/XTR FOX Float X2 Bike Geometry

Pivot Firebird Pro XT/XTR FOX Float X2 Bike Mountain Bike Geometry
Size:
S
M
L
XL
B. Seat Tube (c-t)
375
410
440
470
C. Top Tube Length
597-598
623-624
640-641
664-665
D. Head Tube Length
95
108
118
128
E. Chain Stay Length
430-431
433-434
437-438
444-445
G. Seat Tube Angle
76.0-76.5
76.5-77.0
77.0-77.5
77.0-77.5
H. Head Tube Angle
64.0-64.6
64.0-64.6
64.0-64.6
64.0-64.6
I. Stand Over Height
662-667
672-678
693-699
704-709
J. Wheel Size
29"
29"
29"
29"
K. Stack
612-615
624-627
633-636
642-645
L. Reach
445-450
468-473
488-493
510-515

Pivot Firebird Pro XT/XTR FOX Float X2 Bike Video
